Hampton offer fencing solutions for Zoos and Animal Parks that combine increased strength and low maintenance along with ease of installation and superior quality.
Deer Fencing
Hampton NET™ Deer Fencing available up to 2.6 metres high available.
Mesh sizes can be as versatile as your requirements require, helping two ensure deer legs are safe from entrapment and injury but predators are excluded. Below details some of our more popular mesh patterns suitable for deer but we have the flexibility to produce Hampton NET fencing specifically to your requirements, so please contact us for more information.
-
500 metre rolls available
Pattern | No. Line Wires | Roll Height (cm) | Distance Between Stay Wires (cm) | Standard Roll Length (metres) | Maximum Roll Length (metres) | See Pattern Layout |
13/190/15 | 13 | 190 | 15 | 100 | 500 | |
13/190/22.5 | 13 | 190 | 22.5 | 100 | 500 | |
13/190/30 | 13 | 190 | 30 | 100 | 500 | |
18/208/15 | 18 | 208 | 15 | 100 | 500 |
Sentinel Hinge Joint Stock Fencing
Hampton's Sentinel Hinge Joint fencing is available in various mesh sizes and patterns and suitable for many applications including horse fencing, stock fencing, forestry fencing.
All our Sentinel hinge joint fences are manufactured to BS EN 10223 and unless otherwise requested, all wires used are manufactured to BS4102 and galvanised to BS EN 10244-2 Class A.
Furthermore we recognise that our customers are professionals who understand their own requirements and who need to buy with confidence and ease.
-
500 metre rolls available
-
Quickfencer approved
Top & Bottom Line Wires | Intermediate Line Wires | Stay Wires | ||||
Grade | Nominal Wire Dia. (mm) | Minimum Tensile Strength (N/mm2) | Nominal Wire Dia. (mm) | Minimum Tensile Strength (N/mm2) | Nominal Wire Dia. (mm) | Minimum Tensile Strength (N/mm2) |
L | 2.50 | 695 | 1.90 | 695 | 1.90 | 695 |
C | 3.00 | 695 | 2.50 | 695 | 2.50 | 695 |
B | 4.00 | 695 | 3.00 | 695 | 3.00 | 415 |
LHT | 2.00 | 1100 | 2.00 | 1100 | 2.00 | 695 |
HT | 2.50 | 1235 | 2.50 | 1235 | 2.50 | 695 |
Fencing for Wolves
One of the core features that sets Hampton NET™ fencing apart from other fencing solutions is its versatility.
Hampton NET™ is manufactured to BS EN 10223-5 and unless otherwise requested, all wires used are produced to BS4102 and galvanised to BS EN 10244-2 Class A.
Hampton NET™ Fencing for Wolves
Item | No. Line Wires | Roll Height (cm) | Distance between Stays (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) |
25/242/10 | 25 | 242 | 10 | 100 | 300 |
Fencing for Bears
The smooth animal friendly, knotted joint helps maintain rigidity and form, locking horizontal and vertical wires tight thereby providing a reliably safe and incredibly strong enclosure suitable for bears.
With fence heights available up to an incredible 2.6 metres, Hampton NET™ easily meets the specification required for Bears.
Hampton NET™ Fencing for Bears
Item | No. Line Wires | Roll Height (cm) | Distance between Stays (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) |
20/244/15 | 20 | 244 | 15 | 100 | 500 |
Galvanised Chain Link Fencing
Manufactured to BS EN 10223-6
Wire produced to BS 4102
Galvanised to BS EN10244-2 Class A
50mm mesh as standard
Other mesh sizes available
Available as low (under 600N/mm²) or high (over 600N/mm²) tensile
Galvanised Chain Link Fencing
Wire Diameters (mm) | 2.50 | 3.00 | 3.55 | 2.50 | 3.15 |
Tensile Strength | Low/High | Low/High | Low/High | 1050 N/mm² | |
Typical Heights (mm) | Standard Roll Lengths (metre) | ||||
900 | 25 | 25 | 12.5 | 25 | 25 |
1050 | 25 | 25 | 12.5 | 25 | 25 |
1200 | 25 | 25 | 12.5 | 25 | 25 |
1400 | 25 | 12.5 / 25 | 12.5 | 25 | 12.5 |
1500 | 25 | 12.5 / 25 | 12.5 | 12.5 | 12.5 |
1800 | 25 | 12.5 / 25 | 12.5 | 12.5 | 12.5 |
2000 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
2100 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
2150 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
2400 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
2750 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
3000 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
3050 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
3600 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
Horse and Foal Fencing
Hampton NET™ foal and horse fencing features an animal friendly smooth joint reducing the risk of injury to horses and people. Providing a stronger horse fencing option than more traditional equine fencing options.
Smaller mesh sizes can provide reassurance that foal and horse legs avoid entrapment, a safer foal fence and horse fencing option.
Manufactured to BS EN 10223-5. Wire produced to BS 4102 and fully galvanised to BS EN 10244-2 Class A.
Hampton NET™ is the revolutionary horse fencing option for all discerning horse owners and breeders.
We have invested in purpose built equipment to produce horse fencing that raises the bar both in terms of strength, functionality and safety.
Manufactured at our factory in Northamptonshire, Hampton NET™ foal and horse fencing features the smooth, animal friendly yet strong knotted joint.
The versatility of Hampton NET™ is truly amazing; mesh sizes can be as varied as your application giving you the opportunity to influence the design of your own fence.
-
Quickfencer approved
Pattern | No. Line Wires | Roll Height (cm) | Distance between Stays (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) | See Pattern Layout |
12/107/7.5 | 12 | 107 | 7.5 | 50 | 200 | |
13/122/5 | 13 | 122 | 5 | 50 | 150 | |
13/122/7.5 | 13 | 122 | 7.5 | 50 | 200 | |
15/158/7.5 | 15 | 158 | 7.5 | 50 | 200 |
Pattern | No. Line Wires | Roll Height (cm) | Distance Between Stay Wires (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) | See Pattern Layout |
13/122/5 | 13 | 122 | 5 | 50 | 150 |
Tree and Pheasant Friendly Fencing
Hampton NET™ for trees fencing offers the combination of increased strength, low maintenance and ease of installation with built-in quality. Pheasant friendly fencing allows pheasants to pass freely through the mesh.
manufactured to BS EN 10223-5. Wired produced to BS 4102. Fully galvanised to BS EN 10244-2 Class A.
All these fences are available as either HNHT or HNLHT.
We also have a range of forestry fencing and zoo animal fencing solutions available.
-
500 metre rolls available
-
Quickfencer approved
Pattern | No. Line Wires | Roll Height (cm) | Distance Between Stay Wires (cm) | Standard Roll Length (metres) | Maximum Roll Length (metres) | See Pattern Layout |
5/53/15 | 5 | 53 | 15 | 100 | 500 | |
5/60/15 | 5 | 60 | 15 | 50 | 100 | |
8/80/15 | 8 | 80 | 15 | 50/100 | 500 |
Otter Fencing
About Hampton’s Otter Fencing
Our steel wire otter fencing solutions safely and successfully exclude otters without harming them. Protected by EC and European Law, otters can be one of the most destructive predators, so our specialist otter fencing offers an appropriate solution.
Hampton NET™ for otters has the versatility to withstand even the most cunning of otter attacks. It boasts incredibly strong joints, preventing otters from forcing the wires apart, while remaining aesthetically sympathetic.
Hampton’s otter fencing is offered up to 228cm high with small apertures and includes a hinged, angled top section, effectively preventing otters climbing up and over.
Customers can opt for either a single fence specification with the lower section buried creating a mesh barrier to any otters attempting to burrow under, or a two fence system which features a skirt laying at ground level to similarly help with exclusion of otters.
The low profile knotted joint has no protruding ends so, whilst helping to exclude the otters, they are kept from harm.
You can find more of our products that have been supplied for projects in these case studies.
For crank brackets, hog rings and other tools to aid Otter fence erection, please see our Accessories page.
Technical Specification
Customers can choose our two combinations of otter fencing - erecting Hampton's 19/183/5c with a hinged upper section to be angled out and the separate smaller hinged section, 6/51/5a to provide a 'skirt' along the ground preventing otters from burrowing to gain access.
There is also the 22/228/5 pattern.
Manufactured to BS EN 10223-5
Wire produced to BS 4102
Fully galvanised to BS EN 10244-2 Class A
Pattern | No. Line Wires | Roll Height (cm) | Distance between Stays (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) | Pattern Drawing |
19/183/5c + | 19 | 183 | 5 | 50 | 200 | |
6/51/5a | 6 | 51 | 5 | 50 | 200 | |
22/228/5 | 22 | 228 | 5 | 50 | 100 |
Sentinel Hinge Joint Deer Fencing
Available in a variety of mesh patterns and grades of wire, Hampton's quality Sentinel hinge joint deer fencing is designed to provide the best hinge joint system for either enclosure or exclusion of deer and elk.
All our fences are manufactured to BS EN 10223-5 and unless otherwise requested, all wires used are manufactured to BS 4102 and Galvanised to BS EN 10244-2 Class A.
Pattern | No. Line Wires | Roll Height (cm) | Distance Between Stay Wires (cm) | Standard Roll Length (metres) | Maximum Roll Length (metres) | See Pattern Layout |
13/190/15 | 13 | 190 | 15 | 50 | 100 |
Hampton Net Lamb and Stock Fencing
UK manufactured fixed knot fencing for superior strength and versatility. Hampton Net fully galvanised wire stock fencing.
At Hampton's we pride ourselves on producing the best quality stock fencing products supported by a first rate customer service team; all from our UK based manufacturing plant.
Available in a wide variety of heights, mesh sizes and grades of wire, Hampton's fixed knot fencing Hampton Net is manufactured to BS EN 10223-5, wire produced to BS 4102 and fully galvanised to BS EN 10244-2 Class A.
Below we list some of the more popular patterns.
-
500 metre rolls available
-
Quickfencer approved
Pattern | No. Line Wires | Roll Height (cm) | Distance between Stays (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) | See Pattern Layout |
8/80/15 | 8 | 80 | 15 | 100 | 500 | |
8/80/22.5 | 8 | 80 | 22.5 | 100 | 500 | |
8/80/30 | 8 | 80 | 30 | 100 | 500 | |
8/90/22.5 | 8 | 90 | 22.5 | 100 | 500 | |
8/90/30 | 8 | 90 | 30 | 100 | 500 | |
8/100/15 | 8 | 100 | 15 | 100 | 500 | |
8/100/30 | 8 | 100 | 30 | 100 | 500 |
Fencing for Wolves
Quality fencing for wolves
One of the core features that sets Hampton NET™ wolf fencing apart from other fencing solutions is its versatility. Line wires can be spaced from 2" upwards in 1" increments and stay wires set between 2" and 48".
Hinged Line - An optional hinged upper or lower section designed to be angled out to help prevent scaling or burrowing.
Hampton NET™ fencing is manufactured to BS EN 10223-5 and unless otherwise requested, all wires used are produced to BS4102 and galvanised to BS EN 10244-2 Class A.
We also offer:
Item | No. Line Wires | Roll Height (cm) | Distance between Stays (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) |
25/244/10 | 25 | 244 | 10 | 100 | 300 |
Boar Fencing
Hampton NET™ boar fencing is tough enough to withstand impact from boar and flexible enough to guard against injury. The destructive nature of wild boar makes it imperative to ensure the fencing used to contain or exclude the boar is incredibly strong and secure. Hampton NET™ fencing for boars features fixed knotted joints that lock the horizontal and vertical line wires tight, reducing the risk of the boar forcing their way through the netting.
We also offer fencing for:
Hampton NET™ Fencing for Boars
Item | No. Line Wires | Roll Height (cm) | Distance between Stays (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) |
8/80/7.5 | 8 | 80 | 7.5 | 100 | 200 |
Bear Fencing
The smooth animal friendly, knotted joint helps maintain rigidity and form, locking horizontal and vertical wires tight thereby providing a reliably safe and incredibly strong enclosure suitable help in the fencing of bears.
With fence heights available up to an incredible 2.6 metres, Hampton's NET™ bear fencing easily meets the required specification.
We also provide fencing for:
Hampton NET™ Fencing for Bears
Item | No. Line Wires | Roll Height (cm) | Distance between Stays (cm) | Typical Roll Length (metres) | Maximum Roll Length (metres) |
20/244/15 | 20 | 244 | 15 | 100 | 500 |
PVC Coated Chain Link Baboon Fencing
Hampton's black PVC coated chain link fencing is perfect for various animal housing projects. Alternatively we have fencing for various applications and animals including:
PVC Coated Chain Link for Baboons
Product | 2.50/1.70 | 3.15/2.24 | 3.55/2.50 | 4.00/3.00 | 4.75/3.55 |
Finished Diameter (mm) | 2.5 | 3.15 | 3.55 | 4 | 4.75 |
Core Diameter (mm) | 1.7 | 2.24 | 3 | 3 | 3.55 |
Tensile Strength | Low/High | Low/High | Low/High | 1050 N/mm2 | |
900 | 25 | 12.5/25 | 12.5/25 | 12.5 | 12.5 |
1050 | 25 | 12.5/25 | 12.5/25 | 12.5 | 12.5 |
1200 | 25 | 12.5/25 | 12.5/25 | 12.5 | 12.5 |
1400 | 25 | 12.5/25 | 12.5/25 | 12.5 | 12.5 |
1500 | 25 | 12.5/25 | 12.5/25 | 12.5 | 12.5 |
1800 | 25 | 12.5/25 | 12.5/25 | 12.5 | 12.5 |
2000 | 12.5 | 12.5 | 12.5 | 12.5 | |
2100 | 12.5 | 12.5 | 12.5 | 12.5 | |
2150 | 12.5 | 12.5 | 12.5 | 12.5 | |
2400 | 12.5 | 12.5 | 12.5 | 12.5 | |
2750 | 12.5 | 12.5 | 12.5 | 12.5 | |
3000 | 12.5 | 12.5 | 12.5 | 12.5 | |
3050 | 12.5 | 12.5 | 12.5 | 12.5 | |
3600 | 12.5 | 12.5 | 12.5 | 12.5 |
Badger Fencing
Hampton NET™ Fencing can help to reduce the spread of Bovine TB.
Hampton NET™ badger fencing solution is designed to protect and help safely exclude badgers.
Combining the versatility and strength of the Hampton NET™ with a hinged lower section provides the ultimate in badger fencing. The lower section is angled out and buried a minimum of 450mm into the ground, helping to guard against badgers burrowing under to gain access.
Smaller apertures and the superior strength of Hampton NET™ protects the badger from entrapment and helps safely prevent access.
Manufactured to BS EN 10223-5. Wire produced to BS 4102. Fully galvanised to BS EN 10244-2 Class A.
Also available from stock and trusted by fencing professionals across the UK and overseas, Hampton's own manufactured and fully galvanised chain link fencing.
We also provide fencing for:
Hampton NET™ Fencing for Badgers
Pattern | No. Line Wires | Roll Height (cm) | Distance Between Stay Wires (cm) | Standard Roll Length (metres) | Maximum Roll Length (metres) | See Pattern Layout |
15/158/7.5 | 15 | 158 | 7.5 | 50 | 200 | |
17/193/7.5 | 17 | 193 | 7.5 | 50 | 200 | |
19/239/7.5 | 19 | 239 | 7.5 | 50 | 200 |
Hexagonal Wire Poultry Netting
Available in a variety of mesh sizes and heights, Hampton's premium hexagonal wire netting is produced to meet the highest standards using the best quality wire.
Fully Galvanised After Manufacture to BS EN 10223-2: 2012 tables 2 and 4
Description | Height | Mesh | Wire |
900/19/22g | 900 | 19 | 0.7 |
1200/19/22g | 1200 | 19 | 0.7 |
1200/19/20g | 1200 | 19 | 0.9 |
1200/19/19g | 1200 | 19 | 1.0 |
600/31/19g | 600 | 31 | 1.0 |
900/31/19g | 900 | 31 | 1.0 |
1050/31/19g | 1050 | 31 | 1.0 |
1050/31/18g | 1050 | 31 | 1.2 |
1200/31/19g | 1200 | 31 | 1.0 |
1200/31/18g | 1200 | 31 | 1.2 |
900/50/19g | 900 | 50 | 1.0 |
1200/50/19g | 1200 | 50 | 1.0 |
1800/50/19g | 1800 | 50 | 1.0 |
Fully Galvanised Before Manufacture to BS EN 10244-2: Class A
Description | Height | Mesh | Wire |
900/50/20g | 900 | 50 | 0.9 |
Tiger Fencing Suppliers
Galvanised chain link fencing provides the superior perimeter for the Sumatran Tiger enclosure at Chester Zoo.
Hampton Steel are experienced in the production and supply of excellent quality fencing for animals at zoos and animal parks, impeccable customer service is paramount.
The state-of-the-art Sumatran Tiger enclosure was one of the most complex designs, click here to read the case study.
Manufactured to BS EN 10223-6.
Wire produced to BS 4102.
Galvanised to BS EN10244-2 Class A.
50mm mesh as standard.
Other mesh sizes available.
Galvanised Chain Link
Wire Diameters (mm) | 2.50 | 3.00 | 3.55 | 2.50 | 3.15 |
Tensile Strength | Low/High | Low/High | Low/High | 1050 N/mm2 | |
Typical Heights (mm) | Standard Roll Lengths (metres) | ||||
900 | 25 | 25 | 12.5 | 25 | 25 |
1050 | 25 | 25 | 12.5 | 25 | 25 |
1200 | 25 | 25 | 12.5 | 25 | 25 |
1400 | 25 | 12.5/25 | 12.5 | 25 | 12.5 |
1500 | 25 | 12.5/25 | 12.5 | 25 | 12.5 |
1800 | 25 | 12.5/25 | 12.5 | 25 | 12.5 |
2000 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
2100 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
2150 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
2400 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
2750 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
3000 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
3050 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
3600 | 12.5 | 12.5 | 12.5 | 12.5 | 12.5 |
Strainerlok™ - Hampton's Metal Strainer Post Systems
WINNERS IN THE INNOVATION AWARDS CATEGORY AT THE ROYAL HIGHLAND SHOW
UK manufactured Strainerlok™ Hampton's metal strainer post systems (patent GB2537761) incorporating:-
Metal Box strainer systems.
Metal Angle strainer systems.
Strainerlok™ metal angle and box strainer systems conform to BS 1722-2-2020
Strainerlok™ metal angle and box strainers are an excellent long-life alternative to traditional timber strainer assemblies.
Its light weight, yet incredibly strong, magna tubular steel construction allows strainers to be erected easily, often without the need for pre-augured holes.
Hand held post drivers can be used, a real benefit when the terrain prevents vehicular access.
Supplied in both metal box and angle strut options, packs include anti-lift/twist heel and breast plates, bracing wires, Gripples and post/strut connectors providing easy to assemble metal straining systems.
Suitable for fence heights up to 2.6 metres high.
Multiple struts can can attached to any Hampton metal strainer post permitting changes in direction where required.
Combined with Hampton's intermediate metal post system Versalok®, customers can be assured of a fully integrated metal post system.
Note: the wearing of appropriate safety equipment (i.e. safety shoes, gloves and eyewear) is recommended when installing the Hampton strainer systems, Strainerlok™
Magna tube manufactured to EN10305-2, E370 + CR2 S4.
Call 01933 234070 to discuss your fencing and strainer requirements.
Item | 3" Strainer Post | 2" Strut | Anti-lift/twist Plate | 3" Anchor Post | Post/Strut Connector | Nuts and Bolts | 3" Post Cap | Wire bracing rope and Gripple |
Angle End Strainer | 1 | 1 | 2 | 1 | 2 | 9 | 2 | N/A |
Angle Intermediate Strainer | 1 | 2 | 2 | 2 | 4 | 10 | 3 | N/A |
Box End Strainer | 2 | 1 | N/A | N/A | 2 | 11 | 2 | 1 |
Box Intermediate Strainer | 3 | 2 | N/A | N/A | 4 | 17 | 3 | 2 |
VERSALOK® Intermediate Metal Post and Clip System
Hampton's UK manufactured and patented (GB 2541960) metal post and clip system.
Versalok® Post and Clip System conforms to BS 1722-2-2020
Guaranteed for 30 years.
WINNER AT LAMMA 2019 & THE ROYAL HIGHLAND SHOW 2019
With its delta profile this new intermediate metal post is superior in strength and able to accommodate all woven wire fence patterns.
Quick and simple to erect, the Versalok® post has been designed with lozenge shaped holes to easily and securely lock in the patented stainless steel Versalok® clip.
Where required, two clips can be inserted into one hole thereby increasing product versatility.
Combined with Hampton's steel box and angle Strainer Systems, Hampton can provide customers with a fully integrated metal post system.
Posts produced in standard lengths of 1.8m, 2.2m & 2.9m. Other lengths are available (minimum quantities apply)
Versalok® posts are manufactured from high yield strength steel in 1.5mm and 2.5mm thickness.
Versalok® Post and Clip System conforms to BS 1722-2-2020
Combine with Hampton's Strainer Systems to provide a fully integrated metal post system suitable for all woven wire fence specifications.
Contact the Hampton experienced sales team to discuss your requirements 01933 234070
